| High Range Module characteristics : | |||||||||
|
SSM045 |
SSM050 | SSM055 | SSM065 | SSM070 | SSM075 | SSM085 | SSM090 | SSM110 | |
|
Electrical Characterstics@stc of 1000W/m2 250 C AM 1.5) |
|||||||||
|
Normal voltage in volts |
12 |
12 | 12 | 12 | 12 | 12 | 12 | 12 | 12 |
|
Open circuit voltage (Vsc ) in volts |
20.5 |
20.5 | 20.5 | 20.5 | 20.5 | 20.5 | 20.5 | 20.5 | 20.5 |
|
Short circuit current in Amps |
3.13 |
3.53 | 3.88 | 4.53 | 4.87 | 5.30 | 5.92 | 6.27 | 7.7 |
|
Maximum Power (Pm)in watts |
45 |
50 | 55 | 65 | 70 | 75 | 85 | 90 | 110 |
|
Voltage at maximum power (Vmp)in volts |
16.4 |
16.4 |
16.4 |
16.4 |
16.4 |
16.4 |
16.4 |
16.4 |
16.4 |
|
Current at maximum power (Imp)in Amps |
2.74 |
3.05 |
3.35 |
3.96 |
4.27 |
4.57 |
5.18 |
5.49 |
6.71 |
| Output variations |
±5% |
±5% |
±5% |
±5% |
±5% |
±5% |
±5% |
±5% |
±5% |
| Other Characteristics | |||||||||
| Type of Cell | Mono /Multi Crystalline Silicon | ||||||||
| Front Face | Tempered Glass (low Iron) | ||||||||
| Encapsulate | Ethylene Vinyl Acetate | ||||||||
| Frame | Anodized Aluminum | ||||||||
| Junction Box | Weather proof nylon 6 | ||||||||
| Warranty | up to 20 years limited extended warranty | ||||||||
| Small Range Module characteristics : | |||||||||
|
SSM003 |
SSM005 | SSM008 | SSM010 | SSM015 | SSM020 | SSM025 | SSM030 | SSM040 | |
|
Electrical Characterstics@stc of 1000W/m2 250 C AM 1.5) |
|||||||||
|
Normal voltage in volts |
6 |
6/12 | 12 | 12 | 12 | 12 | 12 | 12 | 12 |
|
Open circuit voltage (Vsc ) in volts |
10.2 |
10.2/20.5 | 20.5 | 20.5 | 20.5 | 20.5 | 20.5 | 20.5 | 20.5 |
|
Short circuit current in Amps |
0.42 |
0.7/0.35 | 0.55 | 0.7 | 1.05 | 1.40 | 1.74 | 2.00 | 2.82 |
|
Maximum Power (Pm)in watts |
3 |
5 | 8 | 15 | 20 | 25 | 30 | 35 | 40 |
|
Voltage at maximum power (Vmp)in volts |
8.2 |
8.2/16.4 |
16.4 |
16.4 |
16.4 |
16.4 |
16.4 |
16.4 |
16.4 |
|
Current at maximum power (Imp)in Amps |
0.36 |
0.6/0.3 |
0.48 |
0.62 |
0.91 |
1.22 |
1.5 |
1.80 |
2.43 |
| Output variations |
±5% |
±5% |
±5% |
±5% |
±5% |
±5% |
±5% |
±5% |
±5% |
| Other Characteristics | |||||||||
| Type of Cell | Mono /Multi Crystalline Silicon | ||||||||
| Front Face | Tempered Glass (low Iron) | ||||||||
| Encapsulate | Ethylene Vinyl Acetate | ||||||||
| Frame | Anodized Aluminum | ||||||||
| Junction Box | Weather proof nylon 6 | ||||||||
| Warranty | up to 20 years limited extended warranty | ||||||||
